DJI Ronin 4D 4-Axis Cinema Camera 8K Combo Kit with DL PZ 17-28mm T3.0 ASPH Lens

DJI Ronin 4D 8K Overview

The Ronin 4D 4-Axis Cinema Camera 8K Combo Kit with DL PZ 17-28mm T3.0 ASPH Lens from DJI combines imaging, stabilization, and focusing in a lightweight, uniquely flexible gimbal/camera rig. This 4D X9-8K version pairs the Ronin 4D gimbal with the Zenmuse X9-8K camera, a DJI DL 17-28mm T3.0 lens, a LiDAR range finder, a low-pass filter, and a RAW license that requires activation via DJI; wireless video transmission is available separately. With support for up to 8K60 17:9 video in Apple ProRes RAW, and 8K30 17:9 and 8K75 2.39:1 in ProRes 422 HQ, the X9-8K offers the higher imaging standards required for visual effects, cine-style capture, and broadcasting while reducing your setup time with its all-in-one combination design.

Meet DJI Ronin 4D-8K

RAW License Key and PROSSD 1TB

The Zenmuse X9-8K supports up to 8K video capture and includes both a RAW license key (requires activation via DJI) and the DJI PROSSD 1TB drive, DJI PROSSD mount, and USB-C high-speed data cable required for raw recording.

DL PZ 17-28mm Lens, Low-Pass Filter

In addition to the RAW license key, the X9-8K Combo includes a DL lens mount and the DJI DL PZ 17-28mm T3.0 ASPH lens plus a built-in OLPF (optical low-pass filter) for maximum color accuracy.

Included Components

• Left and right control handgrips

• LiDAR range finder

• Integrated 5.5" monitor

• NOTE: Does not include the high-bright main monitor

• TB50 battery and charging adapter

• Top handle

• Baseplate

• Hard carrying case

Separately Available Components

• 7" high-bright, touchscreen monitor

• Wireless video transmitter

• X9 focus motor

• 3-channel FIZ lens control unit

• Expansion plate with SDI, XLR, and timecode ports

• DJI Leica L and M lens mounts

• Third-party ARRI PL and Sony E lens mounts

Advanced Image Processing with DCCS and ACES

• Support for the industry-standard ACES workflow provides easy compatibility with other cinema cameras.

• The DJI DCCS color science reproduces vivid, natural skin tones in a range of lighting conditions and creates looks that are compatible with ARRI footage.

• The full-frame Zenmuse X9-8Kcamera uses a proprietary chip for advanced processing and high-performance computing.

Z-Axis Camera/3-Axis Gimbal Stabilizing

• Selectable Z-axis stabilization reduces unwanted vertical camera movement, especially during dollying moves.

• Z-axis stabilization is built into the camera; 4-axis stabilization in the gimbal.

• Tilt stabilization uses dual, symmetrical motors.

• Pan and X (roll) axes with additional stiffness buffering.

• Downward ToF (time of flight) sensor.

• Forward and downward-facing dual-vision sensors.

• Built-in IMU (inertial measurement unit) and barometer.

• New and improved stabilization algorithm.

Zenmuse X9-8K Camera with DL Lens Mount

• The D4's DL lens mount supports full-frame capture with DJI's current selection of lightweight, carbon fiber 18, 24, 35, and 50mm lenses.

• Interchangeable lens mounts are available for use with Sony E-mount or Leica M-mount lenses.

• Supports ultrawide, f/0.95 large-aperture, electronic zoom, macro, and anamorphic cine lenses.

• Please see the current lens compatibility list here.

ProRes RAW, 422 HQ, and H.264 4:2:0 10-Bit Capture

• Up to 8K60 ProRes RAW in 17:9 full frame or 5.5K 60 fps ProRes RAW in 17:9 Super35.

• RAW activation required with DJI.

• Up to 8K30 ProRes 422 HQ in 17:9 full frame.

• Up to 8K75 ProRes RAW in 2.39:1 full frame.

• Up to DCI 4K60 ProRes 422 HQ or H.264 in 17:9 full-frame or Super35.

• Up to UHD 4K120 ProRes HQ, HQ LT, or H.264  in full frame.

Dual Native ISO

• With Dynamic Range Expansion off: Dual native ISO 320/1600.

• With Dynamic Range Expansion on: Dual native ISO 800/4000.

• EI 200 to EI 6400.

• 14.7 stops of dynamic range produce nuanced imaging under a range of lighting conditions.

LiDAR Focus Control

• LiDAR (light detection and ranging) system uses up to 43,200 ranging points within a 33' range.

• Excellent focusing performance even in low-light environments.

• Focus pulling can be viewed graphically, thanks to a built-in depth meter.

• Intuitive and highly accurate focusing system.

• Modular LiDAR focusing module attached to the front of the D4 rig.

Autofocus Features

• Maintains focus, even when motion blur is produced by fast-moving subjects.

• Separately available focus motor for use with manual lenses.

• Continuous autofocus is compatible with ActiveTrack Pro, a boon for solo operators.

Automated Manual Focus

• The AMF function (Automated Manual Focus) combines the accuracy of manual focus with the ease of autofocus.

• Operators can grab the focus wheel of the right handgrip at any time to manually focus.

• Handgrip focus wheel uses dynamic damping to provide a physical feel for focus changes.

In-Camera ND Filters

• Built-in ND.03 to ND2.7 filters let you easily adjust to quickly changing lighting conditions.

• Especially handy for outdoor shoots with changing cloud cover.

• Motorized filter system.

ActiveTrack Pro

• DJI's ActiveTrack Pro features combine continuous autofocusing with composition adjustment for professional-looking tracking shots out of the gate.

• ActiveTrack Pro is based on computer vision, deep learning technology, and the computing power of DJI's CineCore 3.0 imaging system.

Dual Focus, Iris, and Control Grips

• Right-hand grip has a focus wheel that doubles as a control for main camera adjustments (menus, exposure, etc.).

• Left-hand grip has a full-range joystick to control pan/tilt; useful when adjusting headroom and more during follow mode.

Single-User or Crew-Assisted Operation

• Top-notch stabilization in a lightweight form.

• Ideal for both solo operators as well as assistant-accompanied shoots.

• Designed to counter footsteps from inexperienced gimbal shooters.

• Works equally well with a single grip, dual grips, shoulder supported, or tripod mounted.

• Sport mode is available with the touch of a button, accommodating faster-paced action.

• Use in standard, underslung, jib, and crane setups.

Media Storage Options

• Requires a ProSSD 1TB drive (included) to capture raw footage.

• USB-C port for external recording; no reader needed to offload footage.

• Integrated CFexpress Type-B card slot.

Built-In 5.5" Touchscreen Monitor

• 5.5" 1920 x 1080 monitor.

• 1000 cd/m² display.

• Touchscreen control.

Audio Recording

• Integrated stereo microphones capture dual-channel 24-bit audio.

• Built-in 3.5mm audio input port and XLR port via expander plate.

Power Options

• Uses the same TB50 intelligent batteries as the Ronin 2 and Inspire 2.

• Each battery provides up to 2.5 hours of capture time.

• Batteries charge fully in approximately 1.5 hours.

• Support auto-heating for cold weather use.

• AC adapter for uninterrupted shooting.
