DJI Ronin 4D 4-Axis Cinema Camera 6K Combo Kit

DJI Ronin 4D 6K Overview

Designed for both solo use by independent creators and dynamic pro video capture, the Ronin 4D from DJI is an innovative all-in-one camera/gimbal solution. The "4D" designation refers to the Z-axis (vertical) stabilization built into the X9-6K camera and the four-axis gimbal stabilization. Constructed from lightweight carbon fiber and an aluminum/magnesium alloy, this system is ideal for independent content creators, indie filmmakers, and event videographers. The full-frame capture at rates up to 6K60 in Apple ProRes 422 HQ and Ronin's CineCore 3.0 image processing system with ACES workflow support also suits the 4D as a "B" or 2nd unit camera for larger cine-style productions.

From Manufacturer

14:13

DJI Ronin 4D All-In-One Gimbal Camera | Hands-on Review

04:08

DJI Ronin 4D: You Didn't Know You Could do THIS

09:39

DJI - Introducing DJI Ronin 4D

All-in-One Camera Gimbal System

• This combo includes the main Zenmuse X9-6K full-frame video camera and a 4-axis gimbal, plus an array of modular monitor, focusing, and control components.

• Kit items include a DL lens mount, a LiDAR range finder, one TB50 battery, a charging hub, and left and right control handgrips.

• This innovative camera gimbal combines imaging, stabilization, and focusing in one lightweight carbon fiber and aluminum/magnesium alloy rig.

• Combination design reduces your setup time at the start of the day and between setups and locations.

Included modular components:

• Left and right control handgrips

• LiDAR range finder

• Top handle

• Baseplate

• X9 3.8 oz counterweight

Separately available components:

• 7" high-bright, touchscreen monitor

• Wireless video transmitter

• ProSSD 1TB media drive

• X9 focus motor

• Leica M lens mount

• 3-channel FIZ lens control unit

NOTE: A wireless video transmitter is not included in this combo kit.

Firmware Update

• Added support for Leica L-mount lenses.

• Manual calibration added for zoom lenses.

• Playback support for anamorphic de-squeeze on High-Bright monitor.

• Supports applied LUTs for HDMI output in clean output.

• Optimized  the camera start-up time.

• Enhanced fine controls in manual focus mode.

• Added playback and zoom control support to handgrips.

• Fixed E-mount lens focus at infinity and manual iris reading.

• Fixed various gimbal settings issues.

• Fixed green tinge on video playback.

• Fixed LiDAR focus issues when waveform appeared normal.

CineCore 3.0 Imaging Processing System

• The Zenmuse X9, DJI's full-frame camera, uses a proprietary chip for advanced processing and high-performance computing

• The Ronin 4D uses the CineCore 3.0 system to support internal ProRes 422 HQ and H.264 video

• Industry-standard ACES workflow support provides easy compatibility with other cinema cameras

Z-Axis Camera/4-Axis Gimbal Stabilizing

• Selectable Z-axis stabilization reduces unwanted vertical camera movement, especially during dollying moves

• Z-axis stabilization is built into the camera; 4-axis stabilization in the gimbal

• Tilt stabilization uses dual, symmetrical motors

• Pan and X (roll) axes with additional stiffness buffering

• Downward ToF (time of flight) sensor

• Forward and downward-facing dual-vision sensors

• Built-in IMU (inertial measurement unit) and barometer

• New and improved stabilization algorithm

Zenmuse X9-6K Camera with DL Lens Mount

• The D4's DL lens mount supports DJI's current selection of lightweight, carbon fiber 18, 24, 35, and 50mm lenses

• Full-frame capture with all but the 16mm DL lens

• Interchangeable lens mounts available for use with Sony E-mount or Leica M-mount lenses

• Supports ultra-wide, f/0.95 large-aperture, electronic zoom, macro, and anamorphic cine lenses

• Please see the current lens compatibility list here

NOTE: The camera is charged via a D-Tap cable; there is no AC adapter option currently available.

ProRes 422 HQ and H.264 4:2:0 10-Bit Capture

• Capture up to 6K60 ProRes 422 HQ video in full-frame 2.39:1

• Capture up to 4K120 ProRes 422 HQ video in Super 35 2.39:1

• Capture up to 2K120 ProRes 422 HQ or H.264 in 17:9 full frame

NOTE: The customer will first have to activate their Ronin 4D unit using DJI Assistant 2 on a computer, which will require them to provide an email address. This is the email address that will receive the ProRes Raw activation key.

Dual Native ISO

• 800/5000 dual native ISO

• EI 200 to 12800

• 14+ stops of dynamic range produce nuanced imaging under a range of lighting conditions

In-Camera ND Filters

• Built-in ND.03 to ND2.7 filters let you easily adjust to quickly changing lighting conditions

• Especially handy for outdoor shoots with changing cloud cover

• Motorized filter system

• Carry in "built" mode for easy company moves

LiDAR Focus Control

• LiDAR (light detection and ranging) system uses up to 43,200 ranging points within a 33' range

• Excellent focusing performance even in low-light environments

• Focus pulling can be viewed graphically, thanks to a built-in depth meter

• Intuitive and highly accurate focusing system

• Modular LiDAR focusing module attached to the front of the D4 rig

Autofocus Features

• Maintains focus, even when motion blur is produced by fast-moving subjects

• Separately available focus motor for use with manual lenses

• Continuous autofocus is compatible with ActiveTrack Pro, a boon for solo operators

Single-User or Crew-Assisted Operation

• Top-notch stabilization in a lightweight form

• Ideal for both solo operators as well as assistant-accompanied shoots

• Designed to counter footsteps from inexperienced gimbal shooters

• Works equally well with a single grip, dual grips, shoulder supported, or tripod-mounted

• Sport mode is available with the touch of a button, accommodating faster-paced action

• Use in standard, underslung, jib, and crane setups

Automated Manual Focus

• The AMF function (Automated Manual Focus) combines the accuracy of manual focus with the ease of autofocus

• Operators can grab the focus wheel of the right handgrip at any time to manually focus

• Hand grip focus wheel uses dynamic damping to provide a physical feel for focus changes

ActiveTrack Pro

• DJI's ActiveTrack Pro features combine continuous autofocusing with composition adjustment for professional-looking tracking shots out of the gate

• ActiveTrack Pro is based on computer vision, deep learning technology, and the computing power of DJI's CineCore 3.0 imaging system

Dual Focus, Iris, and Control Grips

• Right-hand grip has a focus wheel that doubles as a control for main camera adjustments (menus, exposure, etc.)

• Left-hand grip has a full-range joystick to control pan/tilt; useful when adjusting headroom and more during follow mode

Media Storage Options

• USB-C port for external recording, no reader needed to offload footage

• Integrated CFexpress Type-B card slot

NOTE: This camera requires a separate license and a separate ProSSD 1TB drive to capture raw footage.

Built-In 5.5" Touchscreen Monitor

• 5.5" 1920 x 1080 monitor

• NOTE: Does not include the high-bright main monitor

• 1000 cd/m² display

• Touchscreen control

• Rotates for optimal viewing

Audio Recording

• Integrated stereo microphones capture dual-channel 24-bit audio

• Built-in 3.5mm audio input port and XLR port via expander plate

Power Options

• Uses the same TB50 intelligent batteries as the Ronin 2 and Inspire 2

• Each battery provides up to 2.5 hours of capture time

• Batteries charge fully in approximately 1.5 hours

• Support auto-heating for cold weather use

• AC adapter for uninterrupted shooting
