Description
Overview
The HS-1600T Mark II is an all-in-one live video production and streaming solution designed with a single operator in mind. This HDBaseT
switcher uses a single Cat6 cable to provide power, video, camera control and tally lamp, in a compact and portable footprint. The
HS-1600T Mark II brings a new level of simplicity to production workflows. You’ll set up faster and easier thanks to its portable “briefcase”
design and HDBaseT Technology. And thanks to its built-in H.264 web streaming encoder, you can stream your show to virtually any CDN
like YouTube and Facebook at the same time. This increase in flexibility greatly reduces setup time, allowing you to mount the cameras in
challenging locations (like spots without nearby power outlets) It’s volunteer and novice friendly allowing you to produce and stream any
live event meeting, tradeshow, townhall, government event, worship, sports, and musical performances.
Rear Panel I/O Function
1. HDBaseT Port IN x 3
2. HDMI Video IN
3. HDBaseT Port OUT x 1
4. HDMI Video OUT x 2
5. USB F/W Upgrade Port
6. TALLY Output Port
7. AUDIO IN – XLR Balanced CH1/CH2
8. AUDIO IN – Stereo RCA (Left/Right)
9. DC IN
10. Power Switch
11. Stream Port
Front Panel
1. Stream to Facebook Live, YouTube, Twitch, and more
2. Built-in H.264 recorder for SD cards
3. Volume control
4. Preview Program
5. Menu / Power control.
6. Built-in camera control.
7. Switcher / Transitions control.
| Model Name | HS-1600T MKII |
| Product Name | 4-Channel HD/SD HDBaseT Portable Video Streaming Studio |
| Video Standard | HD & SD |
|
Video Format |
1080p 50/59.94/60Hz
1080i 50/59.94/60Hz 720p 50/59.94/60Hz 576i/p 50Hz 480i/p 59.94Hz |
| Input Routable / Crosspoint | N/A |
| Video Input | 3 x HDBaseT
1 x HDMI |
| Computer Graphical Interface | 1 via HDMI |
| Down-Converted Output | Yes |
| Video Output | 3 x HDMI PGM
1 x HDBaseT (RJ-45) 1 x Stream Port (RJ-45) |
|
Analogue Audio Input |
2 x Balanced XLR 1 x Stereo RCA (L/R) De-embedded Digital Audio |
| Analogue Audio Output | 1x Stereo headphone |
| Digital Embedded Audio Support | Input :2 Channel
Output: 2 Channel |
| Audio Delay Calibration | N/A |
| A+V Switching | N/A |
| USK | 1x USK Lumakey support |
| DSK | N/A |
| Picture in Picture | 1 |
| Logo Insertion | N/A |
| Built-in Audio Mixer | Yes, 4 Channels |
| Built-in Monitor Display | 17.3” HD TFT LED backlit, 1920×1080 pixels |
| Built-in Intercom & Tally | N/A |
| Streaming Video Encode | H.264 / AVC, Main/ High Profile Configurable Bit-rate up to 10Mbps |
| Streaming Audio Encode | AAC-LC
Configurable bit rate ranging from 32Kbps to 384Kbps Sample rate: 48KHz, 16bit |
| Streaming Protocol | TS over TCP/UDP (unicast & multicast)
RTSP over HTTP/TCP/UDP (RTSP Elementary Streaming) RTMP/RTMPS (Publish) |
| Streaming Control | Web browser UI for configuration and control Socket commands |
| Recording File System | FAT, exFAT, NTFS |
| Recording File Format | MP4 |
| Recording Setting Control | Web UI for system configuration and control |
| Dimensions (LxWxH) | 455 x 355 x 134 mm |
| Weight | 17.2 Lbs (7.8 Kg), Reinforce Plastic Case |
| Accessory | CB-60/61/62 |
| Power | DC 48V, 4.16A |
| Operating Temp. Range | 0~40 °C |
